LQ075V3DG01 Sales and Technical Information
--------------------------------------------------------------------------------
Product Detail Information
Attribute Name Attribute Data
Active Area 151.78 × 113.76 mm
Backlight System 1 x CCFT
Brightness 400 nits
Contrast Ratio 600:1
Description LCD Displays
Diagonal Size 7.5 inch (19 cm)
Display Mode Normally White
Family LQ075V3DG01
Interface 18-bit digital (6 bits/color)
Operating Temperature Range -30°C to 80°C
Outline Dimensions 183.0 (W) × 139.9 (H) × 12.7 (D) mm
Pixel Format 640 x 480
Response Time 26 ms
RoHS Yes
Status Discontinued
Storage Temperature Range -30°C to 80°C
Type VGA
Viewing Angle - 12 o clock 60 °
Viewing Angle - 6 o clock 65 °
Viewing Angle - side to side 140 °
